Stainless hlau xovxwm haum BSPT txiv neej xov adapter
Stainless txiv neej xov socket Lead Free rau steel EN 10312 yeeb nkab yog qhov ceev thiab yooj yim rau nruab cov kav dej haum nrog kev sib koom ua ke mus tas li. Cov txiv neej adapter no muab kev zoo nkauj tiav thiab tsim los ntawm cov khoom siv tu cev, zoo meej rau cov khoom noj, tshuaj roj, tub yees thiab kev lag luam kev lag luam.
|
2 |
txiv neej threaded yeeb nkab connector |
Loj (mm) |
A (mm) |
Z (mm) |
|
|
15 × Rp1/2 |
55.5 |
32.0 |
|
|
18 × Rp1/2 |
48.0 |
24.5 |
||
|
22 × Rp1/2 |
50.5 |
24.5 |
||
|
22 × Rp3/4 |
56.0 |
30.0 |
||
|
28 × Rp1/2 |
63.5 |
33.0 |
||
|
28 × Rp3/4 |
62.0 |
31.5 |
||
|
28 × Rp1 |
61.0 |
30.5 |
||
|
35 × Rp1 |
71.5 |
34.0 |
||
|
35 × Rp1-1/4 |
76.0 |
38.5 |
||
|
42 × Rp1-1/4 |
80.8 |
34.8 |
||
|
42 × Rp1-1/2 |
84.5 |
38.5 |
||
|
54x 1 np |
112.0 |
56.5 |
||
|
54 × Rp1-1/4 |
108.0 |
52.5 |
||
|
54 × Rp1-1/2 |
91.4 |
35.9 |
||
|
54 × 2 |
101.5 |
46.0 |
||
|
Loj loj |
||||
|
76.1 × Rp1 1/2 |
114.0 |
53.0 |
||
|
88,9x 3 |
110.0 |
40.5 |
||
|
108x 4 |
137.5 |
55.0 |
||
Daim ntawv thov
Kub thiab dej txias installation
Haus dej
Cov cua sov hauv cheeb tsam thiab cheeb tsam
Rainwater sau qoob
Roj-dawb compressed cua
Lub tshuab nqus tsev
Thermal solar systems
Dej raws cua txias
Industrial thiab txheej txheem dej
WRAS Pom zoo rau EPMD thiab FPM cov ntsaws ruaj ruaj
Ua los ntawm Stainless Hlau No.1.4404 (AISI 316L)
Tshwj xeeb tsim O-ring nrog cov cim qhia txog kev xau.
Kev khiav hauj lwm siab: mus txog 25 bar.
Ua haujlwm kub: -20 degree - 110 degree los ntawm EPDM O-ring
-20 degree - 200 degree los ntawm FPM O-ring
Hlau sib npaug xovxwm 90D Lub luj tshib haum tau tshaj cov kav hlau stainless hauv EN10312 Standard:
Tsuas yog siv lub zog los ntawm lub cuab yeej nias kom nruj O-ntiv nplhaib rau hauv lub raj, ua kom lub cev huv si, tsis muaj dej tsis zoo hauv vib nas this uas tsis muaj nplaim taws, solder lossis flux. Lub luj tshib 90 muaj ob lub xovxwm sib txuas. Hom xovxwm haum no muab ib txoj hauv kev hloov cov raj xa dej los ntawm 90 degrees
Luj tshib.
